Dual band, dual display
|
A/B band independent operation
|
|
128 groups channels storage
|
Shortcut menu operation mode
|
|
VFO & Memory channels scan
|
Emergency Alarm
|
|
Tri-color background light selectable
|
0~9 grades VOX selectable
|
|
PTT & ANI ID
|
FM radio and 25 stations storage
|
|
1750Hz Brust Tone
|
Time-out Timer
|
|
Channel Monitor
|
Battery Saver
|
|
Keypad Lock
|
Channel Step: 2.5/5/6.25/10/12.5/25KHz
|
|
Low Battery Alert
|
ROGER SET
|
|
Emergency Alert
|
25KHz/12.5KHz Switchable
|
|
FM Radio (65.0MHz-108.0MHz)
|
Large LCD Display
|
|
LED Flashlight
|
Hight /Low RF Power Switchable
|
|
Voice companding
|
50 CTCSS/ 104DCS coder & tone searching
|
|
dual standby
|
PC programmable
|
|
Wide/Narrow Band(25kHz/12.5kHz)
|
Transmitter time-out timer(TOT)
|
|
High/Low TX power selectable
|
Busy channel lock-out(BCLO)
|
|
Specifications
|
|
General
|
|
Frequency Range
|
65-108MHz(FM Receive only)
|
|
136-174MHZ and 400-520MHZ (TX/RX)
|
|
Channel No.
|
128
|
|
Frequency Stability
|
±2.5ppm
|
|
Antenna
|
High gain DualBand antenna
|
|
Antenna Impedance
|
50Ω
|
|
Operating Voltage
|
DC 7.4V
|
|
Mode of operation
|
Simple or semi-duplex
|
|
Dimension(W x H x D)
|
100 x 52 x 32 mm
|
|
Weight
|
250g(including battery, antenna)
|
|
Antenna :
|
SMA -Female
|
|
Earpiece / mic type :
|
Kenwood Plug type
|
|
Transmitter
|
|
Output power
|
5W / 1W (Max 5W)
|
|
Modulation Mode
|
16kΦF3E / 11kΦF3E
|
|
Maximum deviation
|
5kHz(Wide) / 2.5kHz(Narrow)
|
|
Spurious Radiation
|
7μW
|
|
Adjacent Ch. power
|
≤-65dB(Wide) / ≤-60dB(Narrow)
|
|
Pre-emphasis characteristics
|
6dB
|
|
Current
|
≤1.6A(5W)
|
|
CTCSS/DCS deviation
|
0.5±0.1kHz(Wide) / 0.3±0.1kHz(Narrow)
|
|
Intermediation sensitivity
|
8-12mv
|
|
Intermediation distortion
|
≤10%
|
